KE5224 Oscilloscope DC Power Supply

KE5224 Oscilloscope DC Power Supply

Regular price $875.00
Regular price $891.00 Sale price $875.00
Sale Sold out

Oscilloscope DC Power Supply

Power supply for the Cathode Ray Oscilloscope.

Low voltage power supply with four outputs primarily intended to simultaneously supply power for the Teltron line of electron tubes and Helmholtz Coils, with four independent, adjustable DC voltages. The DC voltages are stabilized, regulated, floating, and galvanically isolated from one another, in addition to being short circuit proof and secure from external voltages.
Specifications:

500 V output:

Voltage: 0 − 500 V DC, max. 50 mA
Stability at full load: ≤0.01% ± 100 mV
Residual ripple: ≤20 mV

50 V output:

Voltage: 0 − 50 V DC, max. 50 mA
Stability at full load: ≤0.1% ± 30 mV
Residual ripple: ≤50 mV

12 V output:

Voltage: 0 − -12 V DC, max. 4 A
Stability at full load: ≤0.1% ± 30 mV

8 V output:

Voltage: 0 − 8 V DC, max. 3 A
Stability at full load: ≤0.1% ± 30 mV

Displays: Analogue, class 2
Connections: 4 mm safety sockets
Power consumption: 50 VA
